Measurable parameters:Cp-D/Q/G/Rp, Cs-D/Q/Rs, Lp-D/Q/G/Rp, Ls-D/Q/Rs, Rs-Xs, Z-θ, Y-θ, G-B
Measurement time mode (Fast/medium):
200ms/500ms at 10Hz
100ms/500ms at 50Hz
20ms/200ms at ≥100Hz
User-defined time range:
100ms/2000ms at 10Hz
20ms/2000ms at 50Hz
20ms/2000ms at ≥100Hz
5ms/2000ms at ≥1kHz
Frequency (at a step of 1mHz): 10Hz-50kHz
Testing signal level (At a step of 1mVrms): 10mVrms ~ 2Vrms; 100μArms ~ 20mArms
Constant voltage level:10mVrms-1Vrms
Constant current level:100μArms-10mArms
Internal resistance of signal source:30 Ohm or 100 Ohm, selectable
Basic accuracy: 0.05%
Display resolution: 5 1/2 digit
Power voltage: 220V.AC ±10%, 50Hz;
Power consumption: <20W
Display: 7” TFT LCD, with a resolution of 800*480
Interfaces: Ethernet, RS232, GPIB, USB and Handler interfaces
Service environment: 0°C-40°C
Sizes: 330mm*285mm*136mm (L*W*H)
Standard accessories:
Three-core power cord
Kelvin clips
Lead-type testing clips
Gilded short circuit bar
Optional accessories:
GPIB cable
RS232 serial port line
USB cable
1m/2m test cable
Patch testing clips
Patch testing clips (with cable)
