EAST TESTER ET3260A True RMS Digital Multimeter (6 1/2 digits, no GPIB interface, no back panel signal input terminal)

Main technical indicators

Display: 3.5-inch color screen (resolution 320*480)

According digits: 6 1/2

Signal terminal: Front end

Maximum measurement speed: 2500 readings per second

Measuring range:

DCV: 0 mV~1000 V

ACV: 1 mV~750 V

DCI: 0 uA ~ 12 A

ACI: 1 uA ~ 12 A

Resistance: 0 Ω ~ 1 GΩ

Frequency/period: 3 Hz ~ 1 MHz

Capacitance: 0 nF ~ 100 mF

On- off/diode: Yes

Proportion (DC:DC):

Reference range: 100mV ~ 10 V

Input range: 100mV ~ 1000 V

Temperature:

Type: Platinum resistance, thermistor, custom sensor

Maximum resolution: 0.001℃

Mathematical functions: Relative to (ax + b), maximum/minimum/average, standard deviation, dB, dBm, read retention, limit test

Graphics: Histogram, trend graph

Interface: RS-232、IEEE 488、LAN、USB Device、USB Host、Trig IN/OUT

Programming language: SCPI Compatible with Agilent 34401A, 34410 and Fluke 45

Data storage capacity: 512K

General technical specifications

Power supply voltage: 220V.AC±10%, 45~66Hz, or 110V.AC±10%, 45~440Hz;

Function: <20W;

Display: 3.5 inch TFT LCD screen, resolution 480 *320, color 16M;

Temperature Range: -5℃~+45℃;

Humidity range: 5%~85% relative humidity;

Interfaces: RS232, USB Host, USB Device, LAN, GPIB (only ET3260 support), Wifi, Bluetooth;

Size and weight: 265mm *105mm *335mm (width *height *depth), weight 2.7Kg.

Standard accessories

Three core Power Supply Wire*1(30A51);

Three core pen*1(32A52);

Backup Power Fuse*2(32A52).

Optional accessories

GPIB cable (32P01);

Cabinet Installation Kit (32P02);

Pt100 temperature probe (32P03);

Rs232 Serial Port Line (32P04);

USB data line (32P05).
