Function / Features
- Certificate : New Excellent Product (NeP)
Certificate of Patent
Certificate of CE
- English Display
- Real Time Trend Graph Function
- Relay Contact output - HH, L, L, LL & Cleaning Contact
- Simple Operation by 7 Keypad Button
- Large Size LCD Screen (160*128)
- Back-Light LCD
- Isolated(4~20, 0~20, 0~24 mA DC) Output Transmission
- RS-232(Std.), RS485(option) Communication
- Automatic Cleaning Control(Air jet, Water jet) Function
- Wall Mounting / 2B pipe Stanchion Mounting
- Microprocessor-based Digital Program Controller
Specifications - Code No. : 41313001DO
- MODEL : DWA-3000A-DO
- Channel : single channel
- Meas. Range : 0 to 20 mg/L (Resolution: 0.01)
- Meas. Method : polarograph
- Power : AC 110/220V, 50/60Hz, 3VA
- Accuracy : ± 1% of F.S
- Repetition &Reappearance : ± 1% of F.S
- Response time : 120 sec(90% saturation)
- Analog output : 4~20mA DC
- Digital output : RS-232C, RS485
- Relay output : HH, H, L, LL & Cleaning Contact
- Display : Trend graph, measuring value, Temp.
- Humidity : max. 90%(non-condensing)
- IP Rating : IP65
- Size : 240(W)x180(H)x115(D)
- Installation : Wall mounting
OPTION:
|
|
D.O ELECTRODE |
|
PRICES (USD) |
|
1 |
Electrodes ONLINE FOR TREATMENT, BODY BY PPS |
1 |
|
|
2 |
Electrodes ONLINE MULTI-PURPOSE, WITH BODY PPS |
1 |
|
|
3 |
Electrodes ONLINE USED IN WATER AND WATER PURITY, BODY BY PPS |
1 |
|
|
4 |
ACCESSORIES FOR POWER POLE D.O |
1 |
|
