Weight: 4.6 lb
Accuracy: ± 1.5 %, ± 3% with transitional flow
Pipe Size: 5/8 in x 3/4 in
Pulse Rates: 10 gal/pulse
Output Detail: Pulse Output with Frequency Proportional to Flow Rate
Output Signal: DC Pulse
Proof Pressure: Up to 150 psi
Electrical Rating: 0.01 A @ 24 Vac/Vdc
Materials, Wetted: ABS, Brass
Transitional Flow: 0.25 GPM
Media Compatibility: Water
Mounting Orientation: Vertical
Electrical Connection: Pigtail Leads
Nominal Flow Rate, Max: 20 gal/min
Process Connection Size: 3/4 in
Process Connection Type: NPT Male
Totalizing Display, Max: 9999999.99 gal
Volumetric Flow Rate, Max: 20 GPM
Volumetric Flow Rate, Min: 1 GPM
Operating Temperature, Max: 122 °F
