Weight: 13.52 lb
Accuracy: ± 1.5 %, ± 3% with transitional flow
Pipe Size: 1 1/2 in
Pulse Rates: 1 gal/pulse
Output Detail: Pulse Output with Frequency Proportional to Flow Rate
Output Signal: DC Pulse
Proof Pressure: Up to 150 psi
Electrical Rating: 0.01 A @ 24 Vac/Vdc
Materials, Wetted: Brass
Transitional Flow: 1.5 GPM
Media Compatibility: Water
Mounting Orientation: Vertical
Electrical Connection: Pigtail Leads
Nominal Flow Rate, Max: 100 gal/min
Process Connection Size: 1 1/2 in
Process Connection Type: NPT Male
Totalizing Display, Max: 9999999.9 gal
Volumetric Flow Rate, Max: 100 GPM
Volumetric Flow Rate, Min: 5 GPM
Operating Temperature, Max: 190 °F
