Weight: 2.9 lb
Accuracy: ± 3 %
Materials: Polycarbonate
Compliance: CE
Display Note: Backlit: 3.27˝ H x 0.74˝ W (83.1 mm x 18.8 mm), 2 line x 16 characters
Display Type: LCD
Accuracy Note: ± 3% of flow reading for >0.98 ft/s (>0.3 m/s)
Output Detail: Analog: 1 opto-isolated: 4-20 mA; Error current: 3.5 mA; Load resistance: 620 Ω max; Pulse: 1 opto isolated MOSFET relay, 500 mA max, 166 pps max, 200 Hz max
Output Signal: Current, DC Pulse
Repeatability: ± 0.15%
Response Time: <1 s
Pipe Size, Max: 7 in
Pipe Size, Min: 5 in
Supply Voltage: 12 to 24 Vac/Vdc
Load Resistance: 620 Ω max
Enclosure Ratings: IP54
Power Consumption: 7 W
Supply Power Type: AC/DC
Repeatability Note: ± 0.15% of measured value
Media Compatibility: Water
Tube Wall Thickness: 0.39 in
Electrical Connection: Cable
Linear Flow Rate, Max: 32.8 ft/s
Linear Flow Rate, Min: 0.33 ft/s
Process Temperature, Max: 185 °F
Process Temperature, Min: 32 °F
Operating Temperature, Max: 122 °F
Operating Temperature, Min: 32 °F
