Drift: 0.5% of setpoint
Weight: 94 g
Compliance: CE
Wire Gauge: 22 AWG
Switch Type: SPDT NO/NC, Selectable
Pressure Type: Gauge
Repeatability: ± 5%
Response Time: 1 to 10 s
Switch Length: 3 in
Switch Rating: 60 Vac/60 Vdc @ 1 A
Velocity, Max: 3 ft/s
Velocity, Min: 0.04 ft/s
Pipe Size, Max: 1.5 in
Pipe Size, Min: 0.75 in
Supply Voltage: 12 to 36 Vdc
Pressure Limits: Up to 150 psi
Sensor Material: Polyvinylidene Fluoride
Viscosity Range: 1 to 200 cPs
Power Consumption: 50 mA
Supply Power Type: DC
Switch Indication: LED for Flow Status
Repeatability Note: ± 5% of setpoint
Media Compatibility: Alkaline solutions, Dilute Acids, Hydraulic Oil, Light Oil, Oil, Solvents, Water, Water-based fluids
Mounting Orientation: None
Pressure Limits Note: 150 psi (10 bar) @25°C, derated @ 1.667 psi (.113 bar)per °C above 25°C
Electrical Connection: Cable
Process Connection Size: 3/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 32 °F
