Keypad: Yes
Accuracy: ± 1 %
Software: SoloCUE
Materials: 316 Stainless Steel, Polycarbonate
Form factor: Pipe Remote mount
Pulse Rates: 100 Hz
Cable Length: 50 ft
Display Note: Keypad: 4-button navigation, membrane keypad with domed tactile feedback Resolution: 128 × 64 pixel LED backlit graphical display; adjustable brightness and timeout
Display Type: LED
Output Detail: Pulse / Frequency /Digital : Two outputs, each selectable as frequency, pulse, forward/reverse flow or alarm output; isolated open collector, 5-30V DC, 50 mA maximum, externally or internally sourced with pullup resistor Digital alarm output: configurable high or low Frequency output: 63 Hz-10 kHz maximum Pulse (totalizer) output: 100 Hz maximum output open collector, pulse width 5-500 ms programmable Analog Output: 0-20 mA and 4-20 mA drive up to 800 Ohms; minimum 16-bit resolution, isolated Open Collector Output: 5 to 30 Vdc, max. 50 mA externally or internally sourced
Repeatability: ±0.2%
Reserved Type: Standard
Velocity, Max: 40 ft/s
Velocity, Min: 0.1 ft/s
Certifications: CE
Data Interface: BACnet MS/TP, Modbus RTU, USB
Pipe Size, Max: 10 in
Pipe Size, Min: 2.5 in
Supply Voltage: 9 to 28 Vdc
Transducer Type: DTTR
Display Language: English, French, German and Spanish selectable
Measurement Type: Transit Time
Electrical Output: 4 to 20 mA, Two Pulse, Frequency
Enclosure Ratings: IP65
Number of Outputs: 4
Supply Power Type: DC
Calibration Option: Factory Calibrated
Repeatability Note: ±0.2% of reading
Process Temperature, Max: 121 °C
Process Temperature, Min: -40 °C
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
