Weight: 1.3 oz
Accuracy: ± 3 %
Materials: Polycarbonate, PBT
Compliance: UL
Switch Type: NPN
switch-type: NPN
Display Note: 2-line LCD display, 4 digits for measured value and 3.5 digits for setup display Display Cycle: Programmable to 100ms, 250ms, 500ms or 1000ms
Display Type: LCD
Accuracy Note: ± 3% of full range
Display Cycle: Programmable to 100ms, 250ms, 500ms or 1000ms
Output Detail: 4 to 20 mA
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 14.5 psi
Pressure, Min: -14.5 psi
Response Time: 2 ms
Switch Rating: 100 mA @ 30 Vdc
Supply Voltage: 12 to 24 Vdc
Load Resistance: 400 Ω max
Pressure Limits: Up to 29 psi
Number of Digits: 4
Materials, Wetted: Brass with Nickel Plating
Power Consumption: 60 mA + Output Current
Supply Power Note: 12 to 24 VDC ± 10% no isolations
Supply Power Type: DC
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Process Connection Note: 1/8˝ NPT, inner connection M5, for 1/8˝ PT contact factory.
Process Connection Size: 1/8 in
Process Connection Type: PT Male
Process Temperature, Max: 122 °F
Process Temperature, Min: 32 °F
Storage Temperature, Max: 149 °F
Storage Temperature, Min: -4 °F
Operating Temperature, Max: 185 °F
Operating Temperature, Min: -40 °F
Zero Setting Adjustable Range: Menu Scalable within the Range
