Weight: 2 lb
Compliance: CSA, UL
Wire Gauge: 18 AWG
Switch Note: 5 A @ 125/250 VAC. 5 A res., 3 A ind. @ 30 VDC. Gold contacts optional
Switch Type: (2) SPDT Snap
Pressure Type: Gauge
Switch Rating: 5 A @ 125/250 Vac; 5 A , 3 A @ 30 Vdc
Pressure Limits: Up to 1500 psi
Enclosure Ratings: Hazardous Location Rated, IP66, NEMA Type 4X
Materials, Wetted: 316 Stainless Steel, Buna-N (NBR), FEP
Mounting Orientation: Not Position Sensitive
Set Point Adjustment: Internal Thumbwheel or Nut
Enclosure Ratings Note: UL listed explosion-proof, Class I, Groups B, C, and D. Class II Groups E, F, and G. Meets NEMA 4X (IP66). CSA optional. Class I, Groups B, C & D. Class II, Groups E, F, & G -20°C ≤ Tamb ≤ 75°C T6 [optional -20°C ≤ Tamb ≤ 40°C T5] Type 4.
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Decreasing Pressure, Max: 1000 psi
Decreasing Pressure, Min: 100 psi
Increasing Pressure, Max: 1500 psi
Increasing Pressure, Min: 150 psi
