Weight: 136 g
Accuracy: ± 1 %
Display Note: 3.5 digit LCD, 0.7" H
Display Type: LCD
Accuracy Note: ± 1% FS, ± 30 Pa model ± 4% FS at 70°F
Mounting Note: Vertical
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 2 inH₂O
Pressure, Min: 0 inH₂O
Proof Pressure: Up to 10 psi
Supply Voltage: 10 to 35 Vdc
Loop Resistance: 0 to 1250 Ω max
Number of Wires: 2
Span Adjustment: Push Button
Thermal Effects: ± 0.099% FS/°C
Number of Digits: 3.5
Electrical Output: 4 to 20 mA
Materials, Wetted: Consult Factory
Power Consumption: max 38 mA
Supply Power Type: DC
Long Term Stability: ± 1% FS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Thermal Effects Note: ± 0.055% FS/°F (0.099% FS/°C), ± 30 Pa model ± 0.13% FS/°F (0.234% FS/°C).
Additional Features 1: Light Grey Overlay Change
Electrical Connection: Screw Terminal
Process Connection Size: 1/8 in
Process Connection Type: Barbed Fitting
Operating Temperature, Max: 48.9 °C
Operating Temperature, Min: -6.67 °C
Material Construction Option: White Overlay
Zero Setting Adjustable Range: Digital push-button
