Drift: ± 0.2% FS/yr
Memory: 32,768 Readings
Weight: 5 oz
Compliance: CE
Input Type: Temperature, Pressure, RH
Resolution: 8 bits (1 in 256)
Stop Modes: Adjustable Delay Stop
Sensor Type: Thermistor
Pressure Type: Gauge
Pressure, Max: 5 psi
Pressure, Min: 0 psi
Clock Accuracy: ± 8 s/day plus one sampling interval
Proof Pressure: 4x Full Scale
Power Consumption: 5 to 10 µA
Pressure Accuracy: ± 1 %
Relative Humidity: 0 to 95%, Non-Condensing
Supply Power Note: 3.6 V TL5134 lithium metal battery, internal, factory replaceable
Supply Power Type: Battery
Number of Channels: 5
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
System Requirements: IBM compatible 386 or above and Windows® 3.1 or later with 2 MB RAM and 2 MB hard drive disk space, one serial port
Temperature Accuracy: ± 1%
Battery Size and Type: 3.6V Li-ion
Electrical Connection: Screw Terminal
Temperature Resolution: 0.7 °F
Operating Temperature, Max: 160 °F
Operating Temperature, Min: -50 °F
Compensated Temperature, Max: 158 °F
Compensated Temperature, Min: 32 °F
