Weight: 0.13 lb
Switch Note: 1 SPST NO, 1 SPST NC. NO and NC switch independent from each other. Resistive: 15 A @ 6 VDC, 8 A @ 12 VDC, 4 A @ 24 VDC; Inductive: 1 A @ 120 VAC, 0.5 A @ 240 VAC
Switch Type: SPST NO/NC
Pressure Type: Gauge
Repeatability: ± 10%
Switch Rating: 15 A @ 6 Vdc, 8 A @ 12 Vdc, 4 A @ 24 Vdc; 1 A @ 120 Vac, 0.5 A @ 240 Vac
Burst Pressure: 750 psi Maximum
Proof Pressure: Up to 500 psi
Pressure Limits: Up to 250 psi
Enclosure Ratings: IP65
Materials, Wetted: Brass, Steel
Repeatability Note: ± 10% of set point
Media Compatibility: Hydraulic Oil, Light Oil, Oil
Set Point Tolerance: ± 15% of range
Mounting Orientation: Not Position Sensitive
Set Point Adjustment: Internal Screw
Electrical Connection: Screw Terminal
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Decreasing Pressure, Max: 90 psi
Decreasing Pressure, Min: 0.5 psi
Increasing Pressure, Max: 112.3 psi
Increasing Pressure, Min: 1.1 psi
Operating Temperature, Max: 248 °F
Operating Temperature, Min: -40 °F
Material Construction Option: Brass
material-construction-option: Brass
