Filter: 0.5 to 15 s (Selectable)
Weight: 12.6 oz
Accuracy: ± 5 %
Display Type: LED
Probe Length: 4 in
Accuracy Note: 5% FS process gas: 32 to 122°F (0 to 50°C); 6% FS process gas: -40 to 32°F and 122 to 176°F (-40 to 0°C and 50 to 80°C)
Output Detail: 4 to 20 mA, isolated 24 V source, 3 or 4-wire connection
Response Time: 1.5 s to 95%
Supply Voltage: 10 to 16 Vac, 12 to 35 Vdc
Loop Resistance: 600 Ω max
Number of Wires: 4
Air Velocity, Max: 2000 FPM
Air Velocity, Min: 250 FPM
Electrical Output: 4 to 20 mA
Power Consumption: 300 mA
Relative Humidity: Non-Condensing
Supply Power Note: 12 to 35 Vdc, 10 to16 Vac. 1.5 A rating required on supply due to initial power surge drawn by transmitter
Supply Power Type: AC/DC
Response Time Note: Flow: 1.5 s to 95% of final value (output filter set to minimum)
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: None
Electrical Connection: Screw Terminal
Process Temperature, Max: 176 °F
Process Temperature, Min: -40 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 32 °F
