Weight: 374 g
Accuracy: ± 0.3 %
Stability: ± 0.5% of upper range limit for six months
Compliance: CSA, FM
Fill Fluid: DC 200 silicone oil
Wire Gauge: 22 AWG
Accuracy Note: ± 0.30% of calibrated span including linearity hysteresis and repeatability (BFSL) at 25°C (77°F) and 12 VDC excitation
Output Detail: 4 to 20 mA DC, limited to 30 mA DC
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 5000 psi
Pressure, Min: 0 psi
Proof Pressure: Up to 45 psi
Supply Voltage: 12 to 30 Vdc
Compliance Note: FM and CSA approved explosion-proof for Class I, Division 1, Groups B, C, and D, Class II Groups E, F, and G Class III
Loop Resistance: 900 Ω max @ 30 V
Span Adjustment: ± 0.16 mA
Thermal Effects: ± 2.0%/50°F (includes zero and span). Between -20 and 180°F (-29 and 82°C). ± 2.0% per 50°F (28°C).
Enclosure Ratings: IP56, NEMA Type 4
Materials, Wetted: 316L Stainless Steel
Supply Power Note: 12-30 VDC (636), 8-14 VDC (636LP), reverse polarity protection
Supply Power Type: DC
Media Compatibility: Air, Gases, Nitrogen, Oil, Oxygen, Solvents, Water
Electrical Connection: 3/4 in NPT female Conduit with Cable
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Process Temperature, Max: 212 °F
Process Temperature, Min: -40 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: -40 °F
Compensated Temperature, Max: 180 °F
Compensated Temperature, Min: -20 °F
Zero Setting Adjustable Range: ± 0.32 mA
