MTBF: 1,000,000 hours
Accuracy: ± 0.075 %
Materials: Aluminum
Stability: ≤0.075% FSO/3 years
Compliance: CE
Damping Time: 0 to 60 s
Accuracy Note: ± 0.075% FS (@ 20°C)
Output Detail: 4 to 20 mA
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 100 psi
Pressure, Min: 0 psi
Response Time: 16 to 480 ms
Burst Pressure: 30 psi Maximum
Set Point, Min: 1.45 psi
Supply Voltage: 10 to 55 Vdc
Turndown Ratio: 100:1
Compliance Note: CE; -IS, -FP suffix: ATEX Compliant 0518 II 2G ia/db IIC T6/T5 Gb Ta<80°C, T5 / II 2D Ex ia/tb IIIC T85°C/T100°C Db. Type Certificate No. KDB 17ATEX0056X. ATEX Standards: EN 60079-0:2012+A11:2013,EN 60079-1:2014, EN 60079-11:2012, EN 60079-26:2015, EN 60079-31:2014. IECEx Compliant: Ex ia/db IIC T6/T5 Gb / Ex ia/tb IIIC T85°C/T100° Db. Certificate of Conformity IECEx KDB 17.0008X. IECEx Standards: IEC 60079-0:2011, IEC 60079-1:2014-06, IEC 60079-11:2011, IEC 60079-26:2006, IEC 60079-31:2013
Thermal Effects: < ± 0.05% span/10°C
Enclosure Ratings: IP66, IP67, NEMA Type 4X
Materials, Wetted: 316L Stainless Steel
Supply Power Type: DC
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Process Connection Size: 1/2 in
Process Connection Type: NPT Male
Operating Temperature, Max: 185 °F
Operating Temperature, Min: -40 °F
