Weight: 1.8 lb
Accuracy: ± 0.1 %
Deadband: ±0.02% of span
Materials: Aluminum, Epoxy
Compliance: CE, CSA, FM
Hysteresis: ± 0.1% of span
Port 1 Size: 1/4 in
Port 1 Type: NPT Female
Port 2 Size: 1/4 in
Port 2 Type: NPT Female
Output Signal: Pressure
Pressure Type: Gauge
Repeatability: ± 0.1% of span
Air Consumption: 0.05 SCFM
Compliance Note: FM Ratings: Explosion-proof for class I division 1, groups B, C, and D. T6, dust ignitionproof for class I, division 1, groups E, F, and G, T6; Intrinsically safe for class I, II, and III, division 1, groups C, D, E, F, and G, T4 hazardous (classified) locations and intrinsically safe for class I, zone 0, group IIB, T4 hazardous (classified) locations and suitable for class I, groups A, B, C, D, T4, and class II and III, division 2, groups F and G, T6 hazardous (classified) locations. CSA Ratings: Class I division 1, groups B, C, and D; Class I, division 2, groups A, B, C and D; Class II, division 1, groups E, F, and G; Class II and III, division 2, groups F and G.
Output Capacity: 4.5 SCFM at 25 psig Supply; 12.0 SCFM at 100 psig Supply
Measurement Type: Current
Enclosure Ratings: IP65, NEMA Type 4X
Supply Power Type: Loop Powered
Media Compatibility: Clean Dry Air
Input Control Signal: 4 to 20 mA
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Pressure Output Range: 3 to 15 psi
Enclosure Ratings Note: Weatherproof NEMA 4X (IP66), explosion-proof and intrinsically safe
Air Supply Pressure, Max: 100 psi
Air Supply Pressure, Min: 5 psi
Storage Temperature, Max: 200 °F
Storage Temperature, Min: -40 °F
Operating Temperature, Max: 160 °F
Operating Temperature, Min: -40 °F
