Weight: 13 oz
Accuracy: ± 0.25% span ± 1°
Isolation: 500 Vac
Input Type: RTD
Output Note: Proportional Isolated Current: 0-20 mA, selectable, into 600 Ohms maximum
Display Note: Two-4 digit, 7 segment, 0.56" high LED
Display Type: LED
Memory Backup: Non-Volatile
Control Action: Selectable for Reverse (Usually Heating) or Direct (Usually Cooling)
Control Output: SSR Relay
Supply Voltage: 100 to 240 Vac/132 to 240 Vdc
Impedance Input: RTD Current: 200 µA
Output Type (A): Current
Output Type (B): N/A
RTD Input Range: -112 to 572 °F
Number of Digits: 4
Enclosure Ratings: IP65, NEMA Type 4X
Power Consumption: max 5 VA
Supply Power Note: 100-240 VAC nominal, ± 10%, 50-400 Hz, single phase; 132-240 VDC nominal, ± 10%
Supply Power Type: AC/DC
Display Resolution: 1° / 0.1°
Current Output Range: 4 to 20 mA
Mounting Orientation: 1/4 DIN
Temperature Sensor Type: RTD
Operating Temperature, Max: 131 °F
Operating Temperature, Min: 14 °F
