Weight: 349 g
Compliance: CE, CSA, FM, UL
Switch Note: 15 A @ 120-480 VAC, 60 Hz. Resistive, 1/8 HP @ 125 VAC,1/4 HP @ 250 VAC, 60 Hz
Switch Type: SPDT NO/NC, Selectable
Pressure, Max: 20 inH₂O
Pressure, Min: 4 inH₂O
Switch Rating: 15 A @ 120-480 Vac, 1/8 HP @ 125 Vac, 1/4 HP @ 250 Vac
Proof Pressure: Up to 45 inH2O
Vent Connection: 1/8 in NPT Female
Materials, Wetted: Consult Factory
Media Compatibility: Air, Argon, Butane, Carbon dioxide, Combustible Gases, Helium, Hydrogen, Methane, Nitrogen, Non-Corrosive Dry Gases, Oxygen, Propane
Mounting Orientation: Horizontal Diaphragm
Set Point Adjustment: Internal Screw
Electrical Connection: 7/8 in knockout with Screw Terminal block
Process Connection Note: 1/8˝ female NPT or 1/4˝ male NPT
Process Connection Size: 1/4 in x 1/8 in
Process Connection Type: NPT Male and Female
Port/Valve Configuration: Additional HP port on back
Operating Temperature Note: 32 to 110°F (0 to 43.3°C). -30 to 110°F (-34.4 to 43.3°C) for dry gas or dry air.
Operating Temperature, Max: 110 °F
Operating Temperature, Min: 32 °F
