Mains Power Supply
• Connection according to IEC/EN60320-1; UL498, CSA 22.2
• Mains supply: 90 V – 264 V AC
• Frequency: 50 / 60 Hz
• Input power:
3100 VA (RMO300GM) 230 V
2800 VA (RMO300GM) 115 V
Output data
• Test currents ranges and load intervals:
up to 200 A (unlimited test time)
300 A (up to 10 min)
Measurement
• Resistance range: 0.1 μΩ – 999.9 mΩ
• Resolution
0.1 μΩ – 999.9 μΩ 0.1 μΩ
1.000 mΩ – 9.999 mΩ 1 μΩ
10.00 mΩ – 99.99 mΩ 10 μΩ
100.0 mΩ – 999.9 mΩ 0.1 mΩ
Data Storage
• 5 000 internal memory locations
Computer Interface
• USB (standard)
• RS232 or Bluetooth (optional)
Display
• LCD screen 20 characters by 4 lines, with backlight, visible in bright sunlight
Dimensions and Weight
• Dimensions (W x H x D): 503 x 406 x 193 mm /19.8 x 15.9 x 7.60 in
• Weight: 14.6 kg / 32.1 lbs
Environmental Conditions
• Operating temperature: -20 ºC to +55 ºC / -4 °F to +131 ºF
• Storage & transportation temperature: -40 ºC to +70 ºC / -40 °F to +158 ºF
• Humidity 0% - 95% relative humidity, non-condensing
