X-ray energy range KV: 30–160 KV
Scintillator material : GOS
Active area length 1: 382 mm
Number of pixels : 3456
Pixel pitch (spacing) : 0.4 mm
Pixel height : 0.6 mm
Pixel width: 0.32 mm
Max scanning speed : 138 cm/s
Min integration time : 0.29 ms
Max integration time : 128 ms
X-Card type : X-Card2 0.4-128G
X-Card number: 27
X-Card arrangement : 3-3-3-3-3-3-3-3-3
Gap among segments: <0.2 mm
IP classification : IP43
Weight : ~34 Kg
Power consumption : ~17 W
A/D resolution : 16 bits
Dynamic range @1pf feedback cap : > 4000
Data digital interface : 16 bits
Interface: GigE (Camera link as an option)
Linearity : > 99 %
Operational voltage : +12V or +24V DC
Operational temperature : 0–65°C
Operational relative humidity (non-condensing) : 30–80%
Storage temperature : -10–70°C
Lifetime under x-ray : 100 kGy
On-board calibration: Yes
Pixel discontinuity correction : Yes
Dead pixel correction : Yes
Binning function Y: es
Averaging and summing function : Yes
Remote firmware upgrade function : Yes
Multi-detector support : Yes
Compliances : CE EMC: EN61326-1:2013, EN61000-3-2:2006+A1+A2 and EN61000-3-3:2008
