- FM300:
Measuring range: 0 ... 750 N
Accuracy: +/– 3 N or 3 % of reading
Stiffness: 25 N/mm
Gap width: 145–510 mm / 5.7-20"
Diameter: 58 mm / 2.2"
Measuring principle: DMS transducer
Dimensions: 290 x 140 x 60 mm / 11.4 x 5.5 x 2.3"
Weight: 1.7 kg / 3.7 lb
- Display device SEB2:
Display device SEB2 data logger unit with LCD display and LED status indicators, control button, serial interface
Optional PC-controlled measurement
9 V battery supply
Real time clock
Memory for 100 measurements
Sensor and PC interface
Peak display
Rating display i. O./n. i. O.
- PC evaluation software PinchPilot:
Multilingual (DE, EN, IT, FR, ES)
Graphic representation of the force curve
Calculation of the standard-relevant characteristic values
Evaluation according to different guidelines possible
Custom policy adjustable
Log printout
Data export (Excel, CSV, PDF)
Optional measuring point identification
- System requirements software PinchPilot (see tab Software/App)
Delivery Scope:
1 x Closing force measuring device FM300 with 2.5 m connection cable
1 x Display device SEB2 separate measured value acquisition module with LCD display, LED display, Membrane button and serial interface
1 x 9V block battery
1 x Transport case with foam insert for the complete scope of delivery
1 x PC connection cable (USB)
1 x USB data stick with PC evaluation software PinchPilot and documentation
1 x Manual
1 x ISO Calibration Certificate
