Dimensions: 23x17x6cm
Unit weight: 1530g
Probe weight: 265g
Battery weight: 280g
Image presentation (projection) mode: Real-time imaging, B Mode, B+B Mode, B+M Mode
Image managing:
Freeze
Zoom 60 – 200% of original image every 20%
Full screen function
Image and cine loop saving in memory (256 images)
Import of images and cine loops from the memory to the screen
Measuring (distance, surface, size, embryo age tables)
Type and probe frequency: rectal probe 5MHz (frequency range: 3.5~7MHz)
Penetration depth: 7, 10, 12cm
Scanning angle: 180º
Display: LED backlit LCD, diagonal 7.0”
Functions management: membrane keyboard
Image and cine loop memory: memory capacity for min. 200 images and 200 cine-loops with date and description
Image transmission: to external memory device through USB2.0
Power supply: external package of Li-Ion batteries, 14.4V, 3.1Ah
Continuous operation on fully charged battery: 4h30min.
Current consumption: about 0.71A
Charging time: about 2.5h (charger Type 2541 LI)
Low battery indicator: graphic indicator – coded by colour and sound signal before automatic switch-off
Operating temperature range: -15°C~45°C
Storage temperature range: 0°C~45°C
The set includes:
a scanner body
1 rectal probe (For AP2 R PC)
2 packs of external Li-Ion batteries
a charger with a set of wires
a bottle of USG gel
a transportation case
the user’s manual
