Poles: 3P + N
Remote signalling: Without
Surge arrester type: Electrical distribution network
Earthing system:
TN-S
TT
Disconnector device type: Associated circuit breaker at 400 V
Complementary
Surge arrester class type: Type 2
Surge arrester technology: MOV + GDT
Nominal discharge current:
Common mode: 20 kA (N/PE)
Common mode: 20 kA (L/N)
Maximum discharge current:
Common mode: 45 kA N/PE
Common mode: 45 kA L/N
[Uc] maximum continuous operating voltage
Differential mode: 275 V L/N
Differential mode: 275 V N/PE
Maximum [Up] voltage protection level: Differential mode <1.5 kV type 2 L/N
Local signalling: Green and red flag
Mounting mode: Clip-on
Mounting support: DIN rail
9 mm pitches: 8
Height: 90 mm
Width: 72 mm
Depth: 66.2 mm
Colour: Grey (RAL 7035)
Response time: <= 25 ns
Connections - terminals: Tunnel type terminal (downside) 5…35 mm² solid or flexible
Tightening torque: 3.5 N.m
