Aircraft
Takeoff Weight
Mavic 3: 895 g
Mavic 3 Cine: 899 g
Dimensions (Folded/Unfolded)
Folded (without propellers) 221×96.3×90.3 mm (Length×Width×Height)
Unfolded (without propellers) 347.5×283×107.7 mm (Length×Width×Height)
Diagonal Length: 380.1 mm
Max Ascent Speed
1 m/s (C mode)
6 m/s (N mode)
8 m/s (S mode)
Max Descent Speed
1 m/s (C mode)
6 m/s (N mode)
6 m/s (S mode)
Max Flight Speed (at sea level, no wind)
5 m/s (C mode)
15 m/s (N mode)
19 m/s (S mode)
Max Service Ceiling Above Sea Level: 6000 m
Max Flight Time (no wind): 46 minutes
Max Hovering Time (no wind): 40 minutes
Max Flight Distance: 30 km
Max Wind Speed Resistance: 12 m/s
Max Tilt Angle
25° (C mode)
30° (N mode)
35° (S mode)
Max Angular Velocity: 200°/s
Operating Temperature: -10° to 40° C (14° to 104° F)
GNSS: GPS + Galileo + BeiDou
Hovering Accuracy Range
Vertical: ±0.1 m (with Vision Positioning); ±0.5 m (with GNSS Positioning)
Horizontal: ±0.3 m (with Vision Positioning); ±0.5 m (with High-Precision Positioning System)
Internal Storage
Mavic 3: 8 GB (available space is approx. 7.2 GB)
Mavic 3 Cine: 1TB (available space is approx. 934.8 GB)
Hasselblad Camera
Sensor: 4/3 CMOS, Effective pixels: 20 MP
Lens
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/2.8 to f/11
Focus: 1 m to ∞ (with autofocus)
ISO Range
Video: 100-6400
Still Image: 100-6400
Shutter Speed: Electronic Shutter: 8-1/8000 s
Max Image Size: Main Unit: 5280×3956
Still Photography Modes
Single shot: 20MP Photos
Automatic Exposure Bracketing (AEB): 20 MP, 3/5 bracketed frames at 0.7 EV
Timed: 20 MP, 2/3/5/7/10/15/20/30/60 s
Video Resolution
Apple ProRes 422 HQ
5.1K: 5120×2700@24/25/30/48/50fps
DCI 4K: 4096×2160@24/25/30/48/50/60/120*fps
4K: 3840×2160@24/25/30/48/50/60/120*fps
H.264/H.265
5.1K: 5120×2700@24/25/30/48/50fps
DCI 4K: 4096×2160@24/25/30/48/50/60/120*fps
4K: 3840×2160@24/25/30/48/50/60/120*fps
FHD: 1920×1080p@24/25/30/48/50/60/120*/200*fps
* Framerates above are recording framerates. Videos will be played as slow-motion videos.
Max Video Bitrate: H.264/H.265 Bitrate: 200 Mbps
Supported File Formats: exFAT
Photo Format: JPEG/DNG (RAW)
Video Formats
Mavic 3: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
Mavic 3 Cine: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
MOV (Apple ProRes 422 HQ)
Tele Camera
Sensor: 1/2-inch CMOS
Shutter Speed: Electronic Shutter: 2-1/8000 s
Lens
FOV: 15°
Format Equivalent: 162mm
Aperture: f/4.4
Focus: 3 m to ∞
ISO Range
Video: 100-6400
Still Image: 100-6400
Max Image Size: 4000×3000
Photo Format: JPEG
Video Formats: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
Still Photography Modes: Single shot: 12MP Photos
Video Resolution
H264/H.265
4K: 3840×2160@30 fps
FHD: 1920×1080@30 fps
Digital Zoom: 4x
Gimbal
Stabilization: 3-axis motorized (tilt, roll, pan)
Mechanical Range
Tilt: -135° to 100°
Roll: -45° to 45°
Pan: -27° to 27°
Controllable Range
Tilt: -90° to 35°
Pan: -5° to 5°
Max Control Speed (tilt): 100°/s
Angular Vibration Range: ±0.007°
Sensing
Sensing System: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft
Forward
Measurement Range: 0.5-20 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed ≤ 15m/s
FOV: Horizontal 90°, Vertical 103°
Backward
Measurement Range: 0.5-16 m
Effective Sensing Speed: Flight Speed ≤ 12m/s
FOV: Horizontal 90°, Vertical 103°
Lateral
Measurement Range: 0.5-25 m
Effective Sensing Speed: Flight Speed ≤ 15m/s
FOV: Horizontal 90°, Vertical 85°
Upward
Measurement Range: 0.2-10 m
Effective Sensing Speed: Flight Speed ≤ 6m/s
FOV: Front and Back 100°, Left and Right 90°
Downward
Measurement Range: 0.3-18 m
Effective Sensing Speed: Flight Speed ≤ 6m/s
FOV: Front and Back 130°, Left and Right 160°
Operating Environment
Forward, Backward, Left, Right, and Upward: Surface with a clear pattern and adequate lighting (lux>15)
Downward: Surface with a clear pattern and adequate lighting (lux >15). Diffuse reflective surface with diffuse reflectivity>20% (e.g. wall, tree, person)
Video Transmission
Video Transmission System: O3+
Live View Quality: Remote Controller: 1080p@30fps/1080p@60fps
Operation Frequency
2.400-2.4835 GHz
5.725-5.850 GHz
Max Transmission Distance (unobstructed, free of interference and aligned with controller)
2.400-2.4835 GHz; 5.725-5.850 GHz
FCC: 15 km
CE: 8 km
SRRC: 8 km
MIC: 8 km
Signal Transmission Ranges (FCC)
Strong Interference (urban landscape, limited line of sight, many competing signals): Approx. 1.5-3 km
Medium Interference (suburban landscape, open line of sight, some competing signals): Approx. 3-9 km
Low Interference (open landscape abundant line of sight, few competing signals): Approx. 9-15 km
Data is tested under different standards in open areas free of interference. It only refers to the maximum, one-way flight distance without considering Return to Home. Please pay attention to RTH prompts in the DJI Fly app during actual flight.
Max Download Bitrate:
O3+: 5.5MB/s (with RC-N1 remote controller)
15MB/s (with DJI RC Pro remote controller)
Wi-Fi 6: 80MB/s*
*Measured in laboratory environments with little interference in countries/regions that support both 2.4GHz and 5.8GHz, and the footage is saved in the built-in SSD or internal storage. Download speed may vary depending on actual conditions.
Latency (depending on environmental conditions and mobile device)
130 ms (with RC-N1 remote controller)
120 ms (with DJI RC Pro remote controller)
Antennas: 4 antennas, 2T4R
Transmitter Power (EIRP)
2.4 GHz: ≤33 dBm (FCC); ≤20 dBm (CE/SRRC/MIC)
5.8 GHz: ≤33 dBm (FCC), ≤30 dBm(SRRC), ≤14 dBm(CE)
Battery
Capacity: 5000 mAh
Voltage: 15.4 V
Charging Voltage Limit: 17.6 V
Battery Type: LiPo 4S
Energy: 77 Wh
Weight: 335.5 g
Charging Temperature: 5° to 40° C (41° to 104° F)
Battery Charger
Input: 100-240 V AC, 47-63 Hz, 2.0 A
USB-C Output: USB-C: 5.0 V⎓5.0 A/9.0 V⎓5.0 A/12.0 V⎓5.0 A/15.0 V⎓4.3 A/20.0 V⎓3.25 A/5.0~20.0 V⎓3.25 A
USB-A output: USB-A: 5 V⎓2 A
Rated Power: 65 W
Charging Hub
Input: USB-C: 5-20 V⎓5.0 A max
Output: Battery: 12-17.6 V⎓5.0 A max
Rated Power: 65 W
Charging Type: Charges three batteries in sequence.
Charging Temperature Range: 5° to 40° C (41° to 104° F)
Car Charger
Input: Car Power Input: 12.7-16 V⎓6.5 A, rated voltage 14 V DC
Output
USB-C: 5.0 V⎓5.0 A/9.0 V⎓5.0 A/12.0 V⎓5.0 A/15.0 V⎓4.3A/20.0 V⎓3.25 A/5.0~20.0 V⎓3.25 A
USB-A: 5 V⎓2 A
Rated Power: 65 W
Charging Time: Approx. 96 minutes
Charging Temperature Range: 5° to 40° C (41° to 104° F)
DJI RC-N1 Remote Controller
Remote Controller Transmission System
When used with different aircraft hardware configurations, DJI RC-N1 Remote Controllers will automatically select the corresponding firmware version for updating and support the following transmission technologies enabled by the hardware performance of the linked aircraft models:
a. DJI Mini 2/ DJI Mavic Air 2: O2
b. DJI Air 2S: O3
c. DJI Mavic 3: O3+
Max Supported Mobile Device Size: 180×86×10 mm (Length×Width×Height)
Operating Temperature: 0° to 40° C (32° to 104° F)
Transmitter Power (EIRP)
2.4 GHz:
≤26 dBm (FCC), ≤20 dBm (CE/SRRC/MIC)
5.8 GHz:
≤26 dBm (FCC/SRRC), ≤14 dBm (CE)
Battery Life: Without charging any mobile device: 6 hr; when charging mobile device: 4 hr
Supported USB Port Types: Lightning, Micro USB, USB-C
