Fall Time: 27 ns
Rise Time: 136 ns
Technology: SiC
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 236 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 550 W
Vgs - Gate-Source Voltage: - 5 V, + 18 V
Typical Turn-On Delay Time: 25 ns
Typical Turn-Off Delay Time: 63 ns
Id - Continuous Drain Current: 150 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 42 S
Rds On - Drain-Source Resistance: 20 mOhms
Vds - Drain-Source Breakdown Voltage: 650 V
Vgs th - Gate-Source Threshold Voltage: 4 V
