Fall Time: 8.5 ns
Rise Time: 18.8 ns
Technology: SiC
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Qg - Gate Charge: 54.6 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 197 W
Vgs - Gate-Source Voltage: - 4 V, + 15 V
Typical Turn-On Delay Time: 9.1 ns
Typical Turn-Off Delay Time: 17.2 ns
Id - Continuous Drain Current: 38.2 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 5 S
Rds On - Drain-Source Resistance: 90 mOhms
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Vgs th - Gate-Source Threshold Voltage: 3.5 V
