Fall Time: 10.8 ns
Rise Time: 6.8 ns
Technology: Si
Unit Weight: 10 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 37.5 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 900 mW
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 5.5 ns
Typical Turn-Off Delay Time: 22.1 ns
Id - Continuous Drain Current: 16 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 5.7 mOhms
Vds - Drain-Source Breakdown Voltage: 60 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
