Fall Time: 8.53 ns
Rise Time: 5.41 ns
Technology: Si
Unit Weight: 30 mg
Channel Mode: Enhancement
Configuration: Dual
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 14 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.34 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 3.95 ns
Typical Turn-Off Delay Time: 15.4 ns
Id - Continuous Drain Current: 30.2 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 10.8 mOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 2.3 V
