Fall Time: 93 ns
Rise Time: 28 ns
Technology: Si
Unit Weight: 65 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Qg - Gate Charge: 42.6 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 2.03 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 20 ns
Typical Turn-Off Delay Time: 117 ns
Id - Continuous Drain Current: 9.1 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 12 S
Rds On - Drain-Source Resistance: 16 mOhms
Vds - Drain-Source Breakdown Voltage: 12 V
Vgs th - Gate-Source Threshold Voltage: 800 mV
