Fall Time: 13.9 ns
Rise Time: 2.8 ns
Technology: Si
Unit Weight: 5 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 550 pC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 500 mW
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 2.1 ns
Typical Turn-Off Delay Time: 21 ns
Id - Continuous Drain Current: 400 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 1.8 S
Rds On - Drain-Source Resistance: 2 Ohms
Vds - Drain-Source Breakdown Voltage: 60 V
Vgs th - Gate-Source Threshold Voltage: 1 V
