Fall Time: 2.3 ns, 2.9 ns
Rise Time: 2.7 ns, 3.5 ns
Technology: Si
Unit Weight: 30 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Dual
Mounting Style: SMD/SMT
Qg - Gate Charge: 6.1 nC, 12.6 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.2 W
Vgs - Gate-Source Voltage: - 10 V, + 10 V
Typical Turn-On Delay Time: 5.1 ns, 4.4 ns
Typical Turn-Off Delay Time: 6.4 ns, 12.4 ns
Id - Continuous Drain Current: 20 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 27 S, 46 S
Rds On - Drain-Source Resistance: 12 mOhms, 6 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1 V, 750 mV
