Fall Time: 568 ns
Rise Time: 175 ns
Technology: Si
Unit Weight: 0.800 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 10 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 1.35 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 79 ns
Typical Turn-Off Delay Time: 885 ns
Id - Continuous Drain Current: 2.5 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 7.9 S
Rds On - Drain-Source Resistance: 65 mOhms
Vds - Drain-Source Breakdown Voltage: 16 V
Vgs th - Gate-Source Threshold Voltage: 1 V
