Diodes Incorporated DGD0507AFN-7 ຕົວຂັບປະຕູ HV ຝ່າຍສູງ, ຝ່າຍຕ່ຳ

Features: Internal Bootstrap Diode Included, Undervoltage Lockout

Shutdown: Shutdown

Fall Time: 18 ns

Rise Time: 16 ns

Logic Type: CMOS, TTL

Technology: Si

Mounting Style: SMD/SMT

Output Current: 2 A

Number of Drivers: 1 Driver

Number of Outputs: 2 Output

Moisture Sensitive: Yes

Supply Voltage - Max: 14 V

Supply Voltage - Min: 8 V

Pd - Power Dissipation: 400 mW

Propagation Delay - Max: 35 ns

Operating Supply Current: 7.3 mA

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
