Diodes Incorporated AZV832MTR-G1 ເອັັບພລິຟາຍເຊີຍການດຳເນີນງານ Sgl/Dual CMOS OpAmp 1.6ເຖິງ 5.5V 0.9mA

Shutdown: No Shutdown

Topology: Dual

Input Type: Rail-to-Rail

Technology: CMOS

Output Type: Rail-to-Rail

Unit Weight: 534.825 mg

Amplifier Type: General Purpose Amplifier

Mounting Style: SMD/SMT

SR - Slew Rate: 450 mV/us

THD plus Noise: - 70 dB

Moisture Sensitive: Yes

Number of Channels: 2 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 1.6 V

Ib - Input Bias Current: 1 pA

Operating Supply Current: 70 uA

Vcm - Common Mode Voltage: - 300 mV to 5.3 V

Ios - Input Offset Current: 1 pA

Output Current per Channel: 150 mA

Vos - Input Offset Voltage: 500 uV

GBP - Gain Bandwidth Product: 1 MHz

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

en - Input Voltage Noise Density: 27 nV/sqrt Hz

CMRR - Common Mode Rejection Ratio: 90 dB

PSRR - Power Supply Rejection Ratio: 80 dB
