Diodes Incorporated APX4558IS-13 ເອັັບແອມປລິເຄີຊັນສອງຊ່ອງ CH ສະຫຼຸບສຽງ OP AMP 3MHz 18V VCC

Gain V/V: 300 V/mV

Shutdown: No Shutdown

Topology: Dual

Output Type: Rail-to-Rail

Unit Weight: 1 g

Amplifier Type: General Purpose Amplifier

Mounting Style: SMD/SMT

SR - Slew Rate: 1.1 V/us

Number of Channels: 2 Channel

Supply Voltage - Max: 15 V

Supply Voltage - Min: 5 V

Ib - Input Bias Current: 150 nA

Operating Supply Current: 1.25 mA

Vcm - Common Mode Voltage: - 14 V to 14 V

Ios - Input Offset Current: 5 nA

Output Current per Channel: 30 mA

Vos - Input Offset Voltage: 500 uV

GBP - Gain Bandwidth Product: 3 MHz

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C

en - Input Voltage Noise Density: 8 nV/sqrt Hz

CMRR - Common Mode Rejection Ratio: 90 dB

PSRR - Power Supply Rejection Ratio: 90 dB
