Diodes Incorporated AP7167-FNG-7 ຕົວຄວບຄຸມແຮງດັນຕໍ່ຕ່ຳພ້ອມ POK LDO 250mV 2.2V - 5.5V

Width: 3.1 mm

Height: 0.55 mm

Length: 3.1 mm

Polarity: Positive

Output Type: Adjustable

Unit Weight: 69.261 mg

Mounting Style: SMD/SMT

Output Current: 1.2 A

Output Voltage: 800 mV to 5 V

Dropout Voltage: 230 mV

Line Regulation: 0.02 %/V

Load Regulation: 1.5 %

Number of Outputs: 2 Output

Quiescent Current: 180 uA

Reference Voltage: 800 mV

Input Voltage - Max: 5.5 V

Input Voltage - Min: 2.2 V

Dropout Voltage - Max: 800 mV at 1 A

Pd - Power Dissipation: 3.1 W

Ib - Input Bias Current: 125 uA

Voltage Regulation Accuracy: 3 %

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
