Dini Argeo CPX5000 ເ຋ວວັນນໍ້າເຄື່ອງອັນດັບການກົດ (5000kg)

Capacity: 5000kg

Minimum load cell verification interval: Vmin = EMax / 10000

Full Scale Output: 2mV/V +/- 0.5%

Non-Repeatability: 0.01% F.S.

Combined Error 0.05%

Temperature effect on zero: 0.02% / 10°C

Temperature effect on full scale output: 0.02% / 10°C

Compensated Temperature Range: -10°C/+40°C

Operating Temperature Range: -20°C/+60°C

Creep error after 30 minutes: 0.02% F.S.

Maximum tolerated excitation voltage: 15 Vdc

Input Resistance: 750 ± 10 Ohm

Output Resistance: 700 ± 5 Ohm

Zero Balance: +/-1% F.S.

Insulation Resistance: >5000 MOhm

Safe Overload: 120% F.S.

4-wire shielded cable, 5 mm diameter: 5 m long
