-Enclosure: Designed to NEMA4X/IP55. Suitable for continuous outdoor use.
-Accuracy:0.1% of capacity up to EDx-50T.* 0.3% of capacity for EDx-75T and above.*
-Repeatability:0.1% of capacity up to EDx-50T.* 0.3% of capacity for EDx-75T and above.*
* Normal resolution mode with Dillon provided shackles.
-Proof Load:150% of capacity up to EDx-75T. 110% of capcity Edx-100T and above.
-Ultimate Overload:See table on reverse.
-Safe Overload:200% of capacity
-Body Protection: Aluminum and alloy steel capacities are powder coated.
-Bearings: Unmatched repeatability attained by needle bearings in
shackle pin holes up to EDx-5T. Shackle pin acts as inner race.
-Shackles: Forged industry standard anchor shackles. Models up to EDx-5T
use precision machined shackle pin. Higher capacities use bar stock pin.
-Display: 128 x 64 dot-graphic LCD display shows up to 6 digits 1.0” (26 mm)
high plus annunciators and softkeys. Digits are .11 inches (3 mm) thick
for unmatched readability.Display Update Rate:2 times per second.
-Peak Capture Rate:10/100/1,000 Hz
-Connector:Recessed sealed connector may be used for serial
communications or connection to a Communicator II remote.
-RS-232 Communication: Print or extract data easily. Continuous output
can drive a scoreboard. Configurable poll character.
-Calibration: Traceable to the National Institute of Standards and
Technology. Certificate included with curve of readings. Passes only
with three consecutive confirming runs, with all points in specification.
-Battery Life: Stand alone EDXtreme with no radio and no backlight lasts
up to 400+ hours. 150 hours continuous with Radio Link System. Use
with two C-Cell alkaline batteries. (When using backlight, battery life
will be reduced, depending on intensity.)
-Operating Temperature:-4° F to 158° F (-20° to 70° C)
-Included with Instrument:All include certificate of calibration, manual
and batteries. Plastic carry case included for EDx-1T to EDx-50T.
-Higher capacities include rugged plywood storage crate. Instruments with shackles include centering spacers (EDx-20T & up) and
shackle storage crate (EDx-20T to EDx-75T). Display backlight.
-Options:Shackles. Radio communications.
-Included with Remote:Carry case and batteries
-Accessories:Rubberized case protector sleeve.
Remote wall mount bracket. Serial and remote cable assemblies.
Datasheet
Option:
Option Hook:
EDx-1T (2.5K): One Oversized Shackle
EDx-2T (5K): One Oversized Shackle
EDx-5T (10K): One Oversized Shackle
EDx-1T (2.5K): Non-swivel hook
EDx-2T (5K): Non-swivel hook
EDx-5T (10K): Non-swivel hook
EDx/EDjr-10T (25K: Non-swivel hook
EDx-20T (50K): Non-swivel hook
EDx-1T (2.5K): Basic swivel hook
EDx-2T (5K): Basic swivel hook
EDx-5T (10K): Basic swivel hook
EDx/EDjr-10T (25K): Basic swivel hook
EDx-1T (2.5K): Swivel-under-load hook
EDx-2T (5K): Swivel-under-load hook
EDx-5T (10K): Swivel-under-load hook
EDx-10T (25K): Swivel-under-load hook
EDx-20T (50K): Swivel-under-load hook
Accessories for EDXtreme:
36057-0022MTS: Cable, computer serial with 9-pin D connector, 12-ft (3.6 m)
46631-0026: Adapter, 9 to 25-pin to convert above to 25-pin serial port
AWT25-501123: Power supply, 100-240 VAC to 5V for "Red" EDXtreme
AWT25-501124: Power supply, 100-240 VAC/5V to RS-232 for "Red" EDXtreme
Accessories for the Communicator II:
AWT05-506447: Communicator II with radio and backlight
AWT20-508224: Wall mount holder
AWT20-508223: Protective rubber sleeve, gray (recommended for outdoor applications)
AWT25-501123: Power supply, 100-240 VAC to 5V for "Red" EDXtreme
AWT25-501124: Power supply, 100-240 VAC/5V to RS-232 for "Red" EDXtreme
36057-0014: Cable, Communicator II to EDXtreme RS-485 cable, 25-ft (7.6 m)
36057-0071: Cable, Communicator II to EDXtreme RS-485 cable, 50-ft (15 m)
36057-0022MTS: Cable, computer serial cable with 9-pin D connector, 12-ft (3.6 m)
46631-0026: Adapter, 9 to 25-pin to convert for use with 25-pin serial port
