Pressure Range: 0-20KN
Crush Speed: The crush speed is adjustable. The speed of the first contact point during extrusion can be set to 1.5cm/s; the speed range of the test process is 0.01~900mm/min / 0.01~1.5cm/sec (Adjustable)
Driving Method: Electric Servo Drive
Unit Conversion: Kg/N/Lb
Crush Range: 0~300MM
Extrusion Accuracy: ±0.5%
Extrusion Remaining Time: 0~99 hours 99 mins 99 secs
Controlling Mode: Split type, computer control
Main Voltage: 1 channel (control via software interface)
Test Space: ≥ W300*D300*H300mm
Overall Dimension: W1200 X D1100 X H1800 mm
Observation window: Laminated 300*300mm explosion-proof glass with explosion-proof membrane
Power Supply: AC 220V 50HZ
The main control software can simultaneously collect the force, displacement and voltage changes in the extrusion process and make corresponding program control according to the test standard requirements.
Testing Conditions
Communication: Using R232, 485 communication interface, ensure the stability and real-time of remote collection, with explosion-proof function
Voltage Acquisition System (Optional):
Resolution: 5mv
Acquisition range: 0-60V
Acquisition channels: 2 (multiple channels can be customized as required)
Temperature Acquisition System (Optional):
Resolution: 0.1°C
Acquisition range: 0-1200°C
Acquisition channels: 2 (multiple channels can be customized as required)
Safety Protection Device: Automatic explosion-proof pressure relief device, smoke exhaust device, fire extinguishing device, video monitoring system, electronic door lock system, safety stop switch
