DEUTSCH - TE Connectivity HDP24-24-23SE-L017 ຮັບຂອງ RECP ASM

Color: Black

Width: 50.8 mm

Gender: Receptacle (Female)

Height: 47.63 mm

Length: 58.67 mm

Material: Plastic

Dimensions: 50.8 mm x 47.63 mm x 58.67 mm

Unit Weight: 56 g

Accessory Type: Plug Housing

Contact Gender: Without Socket Contacts

Current Rating: 13 A

Mounting Angle: Straight

Mounting Style: Panel Mount

Voltage Rating: 250 V

Wire Gauge Max: 14 AWG

Wire Gauge Min: 20 AWG

Housing Material: Polyamide (PA)

Wire Gauge Range: 14 AWG to 20 AWG

Termination Style: Crimp

Ingress Protection: IP67

Number of Positions: 23 Position

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
