DEUTSCH - TE Connectivity DTM06-6S-KIT 6-ທາງ DTM06-6S ແລະ WEG ເທົ່ານັ້ນ

Color: Gray

Pitch: 4.19 mm (0.165 in)

Width: 15.24 mm

Gender: Plug (Male)

Height: 20.75 mm

Length: 30.1 mm

Dimensions: 15.24 mm x 20.75 mm x 30.1 mm

Insulation: Insulated

Unit Weight: 6.808 g

REACH - SVHC: Details

Mating Gender: Receptacle

Contact Gender: Socket (Female)

Current Rating: 7.5 A

Mounting Angle: Straight

Mounting Style: Cable Mount / Free Hanging

Number of Rows: 2 Row

Voltage Rating: 250 V

Wire Gauge Max: 16 AWG

Wire Gauge Min: 20 AWG

Housing Material: Polyamide (PA)

Wire Gauge Range: 22 AWG to 16 AWG

Termination Style: Crimp

Ingress Protection: IP68, IP6K9K

Mating Part Number: DTM04-6P-xxxx

Number of Positions: 6 Position

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
