Maxinmum working pressure: 7.5 / 8.5 / 10.5 / 13 bar(g) ( equivalent to 109 / 123 / 152 / 189 psig )
Capacity(FAD)*:
50Hz (Min-Max): 33.86-56.43 / 33.69-56.15 / 30.47-50.78 / 27.11-45.18 m³/min ( equivalent to 1196-1993 / 1190-1983 / 1076-1793 / 957-1595 cfm )
60Hz (Min-Max) : 30.53-50.88 / 30.5-50.83 / 27.76-46.27 / 24.19-40.32 m³/min ( equivalent to 1078-1797 / 1077-1795 / 981-1634 / 854-1424 m³/min )
Installed motor power: 315kW; 425 hp
driving mode & Cooling method: Direct Driven; W-Water Cooling
Noise level ** (dBA): 80
Dimensions(mm) LxWxH: 3730x2250x2520
Weight (kg): 7140
Air outlet pipe diamete: DN125
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
***) EEI 2- Energy Effiency Index 2, which refers to normal energy saving series
Specifications are subject to change without notice.
