Maxinmum working pressure: 7 / 8 / 10 / 12.5 bar(g) ( equivalent to 102 / 116 / 145 / 181 psig
Capacity(FAD):
13.78-39.37 m³/min (487-1390 cfm)
13.22-37.76 m³/min (467-1333 cfm)
10.73-30.66 m³/min (379-1083 cfm)
9.93-28.36 m³/min (351-1001 cfm)
Installed motor power: 200 kW; 270 hp
IP Grade: IP55
Noise level db(A): 78
Dimensions(mm) LxWxH: 3310*2090*2400
Weight (kg): 4515
Air outlet pipe diamete: DN100
Starting Method: Direct Driven; Air Cooling
EEI: EEI1
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
Specifications are subject to change without notice.
