Maxinmum working pressure: 7.0 / 8.0 / 10.0 / 12.5 bar(g) ( equivalent to109 / 123 / 152 / 189 psig)
Capacity(FAD)*:
50Hz: 1.77 / 1.76 / 1.45 / 1.13 m³/min ( equivalent to 62 / 62 / 51 / 40 cfm)
60Hz: 1.73 / 1.73 / 1.54 / 1.19 m³/min ( equivalent to 61 / 61 / 55 / 42 cfm)
Installed motor power: 11 kW; 15 hp
driving mode & Cooling method: Belt Driven; Air Cooling
Noise level ** : 62
Dimensions(mm) LxWxH: 1050x650x900
Weight (kg): 410
Air outlet pipe diamete: R3/4"
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
***) EEI 2- Energy Effiency Index 2, which refers to normal energy saving series
Specifications are subject to change without notice.
