Delta Electronics, Inc. SG02D2415A ຕົວແປ DC/DC ທີ່ແຍກອອກ, 15Vout, 2W

Width: 13.7 mm (0.539 in)

Height: 9 mm (0.354 in)

Length: 24 mm (0.945 in)

Industry: Medical, Industrial

Unit Weight: 3.750 g

Output Power: 2 W

Input Voltage: 21.6 V to 26.4 V

Mounting Style: Through Hole

Isolation Voltage: 4 kV

Number of Outputs: 2 Output

Moisture Sensitive: Yes

Input Voltage - Max: 26.4 V

Input Voltage - Min: 21.6 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 66 mA

Output Current-Channel 2: 66 mA

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 15 V

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 25 C
