Delta Electronics, Inc. Q80SV54003PRFS ອິສເອລເທດ 14.4-170Vin 54V 2.8A 150W 1/4 ບຣິກ

Width: 39 mm (1.535 in)

Height: 12.7 mm (0.5 in)

Length: 60.6 mm (2.386 in)

Industry: Industrial

Dimensions: 60.6 mm x 39 mm x 12.7 mm

Unit Weight: 88 g

Output Power: 150 W

Input Voltage: 14.4 V to 170 V

Mounting Style: Through Hole

Isolation Voltage: 4.242 kV

Number of Outputs: 1 Output

Input Voltage - Max: 170 V

Input Voltage - Min: 14.4 V

Input Voltage, Nominal: 80 V

Output Current-Channel 1: 2.8 A

Output Voltage-Channel 1: 54 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
