MEASURING
Range:
Pulse-Echo Mode (P-E) – (Pit & Flaw Detection) measures from 0.025 in. to 100 ft. (0.63 mm to 30.48 Meters).
Echo-Echo Mode (E-E): Thru Paint & Coatings) measures from 0.100 to 6.0 in. (mm).
Range will vary +/- depending on the thickness of coating.
Resolution: +/- .001 inches (0.01 mm)
Velocity Range: .0122 to .7300 in./ms 309.88 to 18542 meters/sec
Single and Two point calibration option, or selection of basic material types.
Units: English & Metric
DISPLAY
Display Views:
Large Digits: standard thickness view; Digit Height: 0.700 in (17.78mm).
B-Scan: Cross section view. Display speed variable (10 to 200 readings per second).
Scan Bar: Speed 10Hz. Viewable in B-Scan and Large Digit views.
Bar Graph: Indicates stability of measurement. Viewable in B-Scan and Large Digit views.
PHYSICAL
Weight: 13.5 ounces (with batteries).
Size: 2.5 W x 6.5 H x 1.24 D inches (63.5 W x 165 H x 31.5 D mm).
Operating Temperature: -14° to 140°F (-10° to 60°C).
Keyboard: Membrane switch with twelve tactile keys.
Case: Extruded aluminum body with nickel-plated aluminum end caps (gasket sealed).
Display: 1/8 in. VGA grayscale display (240 x 160 pixels); Viewable area 2.4 x 1.8 in. (62 x 45.7mm). EL backlit (on/off/auto/invert).
Measurement Modes: Pulse-Echo (flaws, pits)
Echo-Echo (thru-paint).
Pulser: 150 volt square wave pulser.
Receiver: Manual or AGC gain control with 50dB range, depending on mode selected.
Timing: Precision TCXO timing with single shot 100MHz 8 bit ultra low power digitizer.
POWER SOURCE
Line Power: USB-C to PC or power outlet.
Batteries: Three AAA cells. Alkaline – 35 hrs, Nicad – 10 hrs and NI-MH – 35 hrs.
Auto power off if idle 5 min.
Battery status icon.
MEMORY:
Data Structure: Grid (alpha numeric).
Screen Capture: Bitmap graphic capture for quick documentation (.tif).
OBSTRUCT to indicate inaccessible locations.
Capacity: 4 GB internal SD card.
Data Output: USB-C 1.1 to PC & OSX connectivity.
