Power Bandwidth: DC-500kHz
Output specifications
Maximum output voltage:
300Vpp/±150V
RL=100Ω; 100Vrms(40Hz-200kHz); 40Vrms(20Hz-500kHz)
RL=300Ω; ±150V(DC-50kHz); ±140V(DC-200kHz); ±55V(DC-500kHz)
Maximum output current: 1.25Arms/3.5App (40Hz-500kHz); ±0.625A (DC-40Hz)
Slew rate: 450V/μs
Output impedance: ≪1Ω+3.2µH
DC offset: ±150V
Voltage current monitor: Voltage and current double channels output monitoring; Voltage attenuation coefficient 1/100; Current attenuation coefficient 1A/0.1V
Voltage current meter: Voltage current meter; RMS value indication
Input form: A/B two channels (Can be added), A/B for the output is in phase
Input impedance: 50Ω/10 kΩ optional
Input voltage: ±10V Maximum
Gain: 20/40/100/200 optional
Maximum output power (sine wave): 130VA
Maximum output power (square wave): 262.5W
Power supply: 220V±10%, 50/60Hz
Maximum power consumption: 300W
Dimensions: 420(W)x360(L)x210(H) mm
Weight: 9kg
