Frequency range: 9kHz to 30MHz
Level
Maximum RF level (CW)
RF attenuation≥20dB: 30dBm(=1W)
RF pre-Amplifier off: 30dBm(=1W)
Maximum pulse voltage: RF attenuation≥20dB: 150V
Resolution ratio bandwidth
Analyzer mode: 1 /2 / 3 / 5 / 10 step from 10Hz to 1MHz (- 3dB)
Receiver mode: Standard: 200Hz, 9kHz, 120kHz （–6dB); Newly added 10kHz and 100kHz (-6dB) extra optional
Preselector: Could be turned off in analyzer mode: 15 tunnel fixed filter
Preset amplifier: Can be turn on/off; 9kHz to 1GHz, 20dB gain, uniformed
Test time: Receiver mode; 1ms to 1.5s
Detector: Receiver mode; Peak, quasi-peak, average value
Displayed average noise level:
Receiver mode, uniformed, Average detector, RF attenuation 0dB
Preset Amplifier off.
9kHz<f<150kHz, bandwidth 200Hz: < 0dBμV
150kHz<f<30MHz, bandwidth 9kHz: < 10dBμV
30MHz<f<1GHz, bandwidth 120kHz: < 20dBμV
Preset Amplifier on
9kHz<f<150kHz, bandwidth 200Hz: < -5dBμV
150kHz<f<30MHz, bandwidth 9kHz: < 0dBμV
30MHz<f<1GHz, bandwidth 120kHz: < 5dBμV
All uncertainty: 9kHz≤f<1GHz: 1.5dB
Power consumption: <100W
